You are in Needle Detectors > Garment
Features
1. Adopting ABS shell, aesthetic appearance;
2. The amount of qualified products, unqualified products and the total
amount of products can be caculated.
3. Applicable for thick or super-thin objects separately.
4. Has the alarm system when the belt leaves the normal track, to ensure
the life length of the belt as long as it can be
5. Equipped with auto-starting device
6. With the design of environment protection concept, auto electricity saving
7. With environment monitor and location indicator for broken needle
8. Auto alarming and auto return fuction.
9. High anti-disturbance and stability, strong reliability, high sensitivity
Specifications
Model Name |
HD 650 CE 10 |
HD 650 CE 15 |
HD 650 CE 20 |
HD 650 CE 30 |
Detecting Method |
Magnetic induction |
Magnetic induction |
Magnetic induction |
Magnetic induction |
Detecting Ability |
1.00mm(Dia) Fe Part |
1.2mm(Dia) Fe Part |
1.5mm(Dia) Fe Part |
2.5mm(Dia) Fe Part |
Detecting Adjustment |
Stepless adjustment |
Stepless adjustment |
Stepless adjustment |
Stepless adjustment |
Detecting Width |
600mm |
600mm |
600mm |
600mm |
Detecting Height |
100mm |
150mm |
200mm |
300mm |
Alarm Mode |
Buzzer&belt stops |
Buzzer&belt stops |
Buzzer&belt stops |
Buzzer&belt stops |
Belt Speed |
30m/min |
30m/min |
30m/min |
30m/min |
Power Supply |
220v.50Hz,single phase |
220v.50Hz,single phase |
220v.50Hz,single phase |
220v.50Hz,single phase |
Rated Out Put |
110w |
110w |
110w |
110w |
Dimension LxWxH |
1650(L)x1050(W)x900(H)mm |
1650(L)x1050(W)x900(H)mm |
1650(L)x1050(W)x900(H)mm |
1650(L)x1050(W)x900(H)mm |
Weight |
200kg Approx |
230kg Approx |
250kg Approx |
360kg Approx |
